DESCRIPTION
Thermocouple Reference System
The TRUrac is a 0°C or elevated temperature thermocouple reference system mounted in a 19” chassis. It has been developed for situations where ambient temperature can be up to 65°C.
The reference temperature is normally set to 0°C or between 45°C and 70°C. For other temperatures please contact Isotech.
An alarm will be activated should the reference temperatures deviate by more than 0.2°C.
High Capacity – up to 200 Thermocouple Junctions
Inside the rack case is a high stability thermal block which has a capacity of up to 100 thermocouple channels, the probe wires being terminated at the rear of the unit on rail mounted screw terminals.
To special order a second thermal block may be fitted to allow a capacity of 200 channels in a single unit.
The customer simply connects their thermocouple wires and copper output wires to these terminals. All the thermocouple cold junctions are inserted into a metal oven block which is accurately temperature controlled.
SPECIFICATION
| Technical Feature | Value |
|---|---|
| Operating Temperature | 0°C (or 45° to 70°C) |
| Ambient Range | 2°C to 65°C |
| Stability | ±0.03°C, errors introduced by thermocouple loading can be removed by adjusting controller offset. |
| Stabilising Time | 10 minutes from 44°C |
| Capacity | Up to 100 Double Junction Channels |
| Input/Output Connections | Klippon Terminals type 1.5 AKZ |
| Alarm facilities | Non-latching relay rated 5 Amps 240V |
| Power | 100 Watts typical 100-130 or 208-240 VAC 50/60Hz |
| Dimensions – 50 to 100 Channels | Height 400mm Width 483mm Depth 312mm |
| Weight | 24kg |
| Accessories | 935-14-54: Platinum Resistance Thermometer, includes UKAS calibration at 0.01°C. 935-17-32: Fan Filter – recommended for high dust environments. |
| How to order | Should be specified uniquely on each order. Please discuss your exact requirements with us before ordering. |
DOWNLOADS
TRUrac Model 847
0°C (or 45° to 70°C)
The TRUrac is a 0°C or elevated temperature thermocouple reference system mounted in a 19” chassis. It has been developed for situations where ambient temperature can be up to 65°C.
- Rack Mounted
- Large Capacity
- Approved for Power Station Use
We are online and ready to chat to you if you need any advice and support, or if you prefer you can fill out the form below.
Or call +44 01704 543830
Related products
-
Read moreIsorac Model 844
